| Brand Name: | HSTECH |
| Model Number: | HS-D441 |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets per month |
High-Capacity LED Bulb Glue Dispensing Machine with Four Work Stations
Introduce
The LED Bulb Glue Dispenser is a specialized automatic device designed primarily for accurately mixing two components of glue (Group A and Group B) in precise ratios and applying them onto the surface of the workpiece. This dispensing machine finds extensive application in bonding, sealing, and filling processes across diverse industries, such as electronics manufacturing, home appliances, automotive, and numerous others.
High-Efficiency Production: This dispenser features a streamlined four-workstation cycle, capable of achieving an impressive designed throughput of 1000 to 1500 pieces per hour, ultimately maximizing productivity and output.
Smart Workpiece Detection: Equipped with an advanced detection system, the machine intelligently assesses the presence of a workpiece before applying glue, ensuring optimal material utilization and minimizing waste.
Customizable Gluing Patterns: The dispenser offers versatile gluing tracks, accommodating full circles, single points, segmented arcs, and other custom patterns tailored to specific workpiece requirements. This flexibility enhances its applicability across various manufacturing scenarios.
Adaptable Working Modes: Users can configure the dispenser to operate in either a four-station or two-station mode, providing the flexibility needed to adjust to different production demands or workpiece types.
Intuitive User Interface: Featuring an easy-to-use touch screen interface combined with physical buttons, the dispenser is straightforward to learn and operate. Different glue types can be programmed with unique settings, optimizing performance based on each material's characteristics. This simplifies setup processes and boosts operational efficiency.
Precise proportion mixing
Equipped with a precisely controlled mixing system to ensure that components A and B are mixed in the set ratio to ensure the performance of the glue.
Efficient automation
The automatic dispensing system improves production efficiency, reduces manual operation, and reduces labor intensity.
Multiple dispensing methods
Supports multiple dispensing methods such as dripping, spraying, and flowing glue to meet different process requirements.
Easy to adjust and operate
The user-friendly interface allows users to easily adjust dispensing parameters such as pressure, speed, and time.
Intelligent control system
Equipped with a PLC or computer control system to monitor the dispensing process in real time to ensure stability and reliability.
Application scenarios:
Electronic Manufacturing
Utilized for encapsulating, bonding components, and sealing circuit boards, enhancing product durability and reliability.
Automotive Industry
Applied for window sealing and interior bonding, ensuring both the sealing effectiveness and aesthetic appeal of vehicles.
Home Appliance Industry
Used in assembling and repairing a variety of home appliances, offering robust connections and sealing solutions.
Crafts and Furniture
Efficiently applies boiled cast glue in woodworking and handicraft production, ensuring high-quality results.
| Model | HS-BD4 |
| MCU | Industrial PLC |
| Programming | Text Demonstration Programmer |
| Drive mode | Precise Stepping Motor |
| Max Dispensing Diameter | 160mm(two station),110mm(four station) |
| Motor Speed | 0 ~ 300 RPM |
| Positioning Accuracy | ±0.1mm |
| Z-axis Adjust Range | 250mm |
| Z-axis Working Travel | 50mm |
| Dimension (L*W*H) | 420mm*532mm*532mm |
| Weight | 35Kg |
| Working Power | AC220V/50~60Hz/200W |
| Working Air Pressure | 0.4~ 0.6Mpa(no condensation) |
| Working Temperature and Humidity | Temperature: 0~40℃,Humidity: 20~90% |
The LED bulb and Par light glue dispenser is tailored for precise glue application to secure lighting components. The Four-station Round Glue Dispenser stands out with its unique design, featuring four stations on a rotating disc positioned at 90-degree intervals. As the revolution motor rotates 90 degrees, the workpiece is smoothly transferred to the next gluing nozzle, ensuring a seamless and continuous operation flow.
An auto-rotation motor rotates the workpiece uniformly during the glue application process, guaranteeing an even and consistent coating. This efficient combination leads to a precise and streamlined gluing process, making it ideal for lighting manufacturers aiming to improve production quality and throughput.
