Four-Station Round Glue Dispensing Machine for LED Bulb Glue Dispenser

Four-Station Round Glue Dispensing Machine for LED Bulb Glue Dispenser

Brand Name: HSTECH
Model Number: HS-BD4
MOQ: 1 set
Price: Negotiable
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month
Detail Information
Place of Origin:
China
Certification:
CE
Product Name:
LED Bulb Glue Dispenser
Power Supply:
AC220V/50~60Hz/200W
Max Dispensing Diameter:
160mm(two Station),110mm(four Station)
Motor Speed:
Max 300mm/s
Repeat Accuracy:
±0.02mm
Warranty:
1 Year
Application:
LED Bulb, LED Par Light
Control Method:
Text Screen
Packaging Details:
Wooden package
Supply Ability:
100 sets per month
Highlight:

LED Bulb Glue Dispensing Machine

,

automatic glue dispensing machine

,

Four-Station Round Glue Dispensing Machine

Product Description

High Quality LED Bulb Glue Dispenser Four-Station Round Glue Dispensing Machine​



Application

This LED bulb and LED Par light glue dispensing machine is designed to apply glue onto their bases for attachment to the lamp housing. For this purpose, a four-station round glue dispensing machine is ideal. The four stations are arranged at 90-degree intervals on a rotating disc. The revolution motor rotates 90 degrees after each cycle to position the workpiece beneath the glue dispensing nozzle. An auto-rotation motor then rotates the workpiece at a consistent speed to ensure an even application of glue.

Specification

Model HS-BD4
MCU Industrial PLC
Programming Text Demonstration Programmer
Drive mode Precise Stepping Motor
Max Dispensing Diameter 160mm(two station),110mm(four station)
Motor Speed 0 ~ 300 RPM
Positioning Accuracy ±0.1mm
Z-axis Adjust Range 250mm
Z-axis Working Travel 50mm
Dimension (L*W*H) 420mm*532mm*532mm
Weight 35Kg
Working Power AC220V/50~60Hz/200W
Working Air Pressure 0.4~ 0.6Mpa(no condensation)
Working Temperature and Humidity Temperature: 0~40℃,Humidity: 20~90%

Machine feature


Here's a revised version of your text:

  1. The machine features four workstations operating in a cycle, with a designed capacity of 1000 to 1500 pieces per hour.
  2. It is equipped with a workpiece detector that determines whether to apply glue or skip the process.
  3. The gluing track can be customized to full circle, single point, segmented arc, or other configurations as needed.
  4. The machine offers flexible working modes, including four-station and two-station options.
  5. It is user-friendly, featuring a touchscreen and buttons for easy learning and operation. Different settings can be configured for different types of glue to ensure optimal performance.
