High-Capacity LED Bulb Glue Dispensing Machine with Four Work Stations
Introduce
LED Bulb Glue Dispenser It is a device dedicated to automatic dispensing, mainly used to mix two components of glue (group A and group B) in proportion and accurately apply them on the surface of the workpiece. This dispensing machine is widely used in bonding, sealing and filling applications in electronic manufacturing, home appliances, automobiles and other industrial fields.
1, Four work stations in cycle, the designed capacity is 1000~1500pcs/h.
2, Equipped work piece detector to decide gluing or skip.
3, Gluing track can be set as full circle, single point or segmented arc etc.
4, Working mode can be four-station or two-station.
5, It is easy to learn and operate with touch screen and buttons, for different glue with different settings ensure the best performance.
Precise proportion mixing
Equipped with a precisely controlled mixing system to ensure that components A and B are mixed in the set ratio to ensure the performance of the glue.
Efficient automation
The automatic dispensing system improves production efficiency, reduces manual operation, and reduces labor intensity.
Multiple dispensing methods
Supports multiple dispensing methods such as dripping, spraying, and flowing glue to meet different process requirements.
Easy to adjust and operate
The user-friendly interface allows users to easily adjust dispensing parameters such as pressure, speed, and time.
Intelligent control system
Equipped with a PLC or computer control system to monitor the dispensing process in real time to ensure stability and reliability.
Application scenarios:
Electronic manufacturing
Used for encapsulating, bonding components, and sealing circuit boards to improve product durability and reliability.
Automotive industry
Carry out window sealing, interior bonding, etc. to ensure the sealing and aesthetics of the car.
Home appliance industry
Used for assembling and repairing various home appliances, providing strong connections and sealing.
Crafts and furniture
Provide efficient application of boiled cast glue in woodworking and handicraft production.
| Model | HS-BD4 |
| MCU | Industrial PLC |
| Programming | Text Demonstration Programmer |
| Drive mode | Precise Stepping Motor |
| Max Dispensing Diameter | 160mm(two station),110mm(four station) |
| Motor Speed | 0 ~ 300 RPM |
| Positioning Accuracy | ±0.1mm |
| Z-axis Adjust Range | 250mm |
| Z-axis Working Travel | 50mm |
| Dimension (L*W*H) | 420mm*532mm*532mm |
| Weight | 35Kg |
| Working Power | AC220V/50~60Hz/200W |
| Working Air Pressure | 0.4~ 0.6Mpa(no condensation) |
| Working Temperature and Humidity | Temperature: 0~40℃,Humidity: 20~90% |
