| Brand Name: | HSTECH |
| Model Number: | HS-D331 |
| MOQ: | 1 pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per week |
Automatic Desktop 3 Axis Single Head PUR Glue Dispensing Machine
Specification
| Model | HS-D331 |
| Voltage | AC110V/220V,50/60Hz,Meanwell brand |
| Dispensing Valve | PUR heating valve |
| X/Y/Z working range | 300/300/100mm |
| XYZ speed | 300mm/s |
| Y platform | 190*150mm |
| Repeat accuracy | 0.02mm |
| Motor | Stepper motor |
| Driven system | Timing blet for X/Y, Z axis screw |
| Document support | CAD,CorelDRAW |
| Loading capacity | X/Y:10kg,Z:5kg |
| Linear Guide | CSK(Taiwan brand) |
| Photoelectric switch | (Germany brand) |
| Cylinder | AirTAC |
| Glue storage | 30ml PUR Syringe type |
| Machine size | 520*585*597mm |
| Gross weight | 50kg |
Features
1.Easy to program,easy to learn and understand.
2.It has the functions of drawing points,lines,faces,arcs,
circles,and continuallytweenofirregular curves torealize any 3D non-planar track path.
3.Thevolume of the glue,the speed of the glue,the timeof dispensing,and the time of stopping the glue can all be programmed.
4.Quickly dot,draw lines and draw circles in the inner,outer wall,vertical surface,gap and spherical surface of the
product.
5.According to the needs of customers,it can be equipped with fixtures,glue guns,controllers,heating temperature control devices,etc.
6.The software has functions such as regional display, translation rotation operation,etc.
7.Adopt trapezoidalacceleration and deceleration,speed preview,micro line interpolation and other technologies.
8.Configure high-speed,low-noiseJapanese stepping motor with precise positioning,quick response,stable performance andlong servicelife.
About Us:
Shenzhen HanSome Technology Co.,Ltd(HSTECH)was estabilished in 2012 by prefessional and experienced engineer who wroked many years in EMS company,we specilized in PCB handling equipments at first, then we develop the PCB depaneling machine and SMT cleaning machine. HSTECH not only have professional technical team for R&D,but also have a outgoing and experienced marketing team for research and develop, grasps products developing directions, updates the products and technics to meet the continue changing demands. In the past years,we have been always keep innovating and exploing to make cost-efficient products to help our customers saving cost and labor, improving the production efficiency at the same time.
HSTECH set the goal for "High quality and Smart”, that based on the concept of "Quality-Oriented and Customer-orented", and combined the industry feature, smart technology persuit for the smart factory.As for the after-sale service, we insist on "responsibility", we will take reaction at the first when we got quality feedbacks,and service our customers all the time.
