| Brand Name: | HSTECH |
| Model Number: | HS-BD4 |
| MOQ: | 1 pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per week |
| Model | HS-BD4 |
| MCU | Industrial PLC |
| Programming | Text Demonstration Programmer |
| Drive mode | Precise Stepping Motor |
| Max Dispensing Diameter | 160mm(two station),110mm(four station) |
| Motor Speed | 0 ~ 300 RPM |
| Positioning Accuracy | ±0.1mm |
| Z-axis Adjust Range | 250mm |
| Z-axis Working Travel | 50mm |
| Dimension (L*W*H) | 420mm*532mm*532mm |
| Weight | 35Kg |
| Working Power | AC220V/50~60Hz/200W |
| Working Air Pressure | 0.4~ 0.6Mpa(no condensation) |
| Working Temperature and Humidity | Temperature: 0~40℃,Humidity: 20~90% |
1.Chinese and English handheld LCD screen operation, easy programming, easy to learn and understand.
2. It has the functions of drawing points, lines, surfaces, arcs, circles, and continuous tweening of irregular curves to achieve any 3D non-planar trajectory path.
3. Excellent teaching function. Supports advanced functions such as array, graphical browsing, 3D ellipse, common graphics library insertion, group editing, etc.
4. Super large capacity 2G high-speed MiniSD file memory, which can store 999 dispensing process files.
3.The amount of glue, thickness, glue speed, dispensing time, and stopping time can be set by parameters.
4. With a dedicated dispensing controller, the glue output is stable, the glue is clean, and the glue is not leaked.
5, with automatic anti-curing function, effectively prevent the glue from solidifying the needle.
6. Powerful PC compatibility. With Logoshop software, you can import various file formats (such as .NC, .AI, .DXF, .JPG,BMP, etc.) generated by mainstream design software.
