Desktop Mini PCB Router Machine with 3 Axis Driven System for Stamp Hole Curved PCBs
Introduction
This automatic PCB router machine is a mini automatic router machine, adopts desktop type, using 3 axis driven system, customzied the PCB fixing fixtures, manual load and unload the PCB for automatic depaneling,it's a easy and cost-effective PCB router machine.
Small and compact design
The size of the whole machine is only 30cm x 30cm x 25cm, suitable for use on a desk or laboratory workbench.
High-precision positioning
Adopting high-precision stepper motor and optical encoder, it can achieve a positioning accuracy of 0.01mm.
Multifunctional processing
It can perform various PCB processing operations such as drilling, cutting, milling, etc. to meet various PCB manufacturing needs.
Friendly operation interface
Equipped with a 7-inch touch screen display, it provides an intuitive operation interface and program editing function.
Automatic tool change system
Built-in automatic tool change system can automatically switch drills and tools of different specifications according to processing requirements.
Efficient and safe cutting
Adopting high-speed spindle motor and high-precision motion system, PCB boards can be cut quickly and efficiently. At the same time, it has a safety protection design.
Strong software and hardware compatibility
Supports common CAD/CAM software and various PCB board making file formats. Applicable to mainstream operating systems such as Windows/Linux.
Low noise and low power consumption
Adopting silent design, the noise is less than 60dB. Low power consumption, only 110V/220V power supply is required.
Main features
1, 3 axis driven system, using step motor.
2, Flexible desktop type, easy to move and adjust.
3, Equipped with the dust-collector, keep the operation table clean.
4, When depaneling different, just replace the fixture and import different program.
5, All the guide and screw lead screw are dust-proof, make sure the machine operating accuracy.
6, Suitable for separating FPC board, aluminum board, FR4,etc.
Sepcfication
| Model | RM-560 | ||
| Driven motor | Step motor | ||
| Spindle routing speed | 50000rpm | ||
| Repeat accuracy | ±0.01mm | ||
| Cutting speed | Max 100mm/s,depend on PCB material | ||
| Resolution | <0.01mm | ||
| Moving range | 300*300*700mm | ||
| Driving system | X/Y/Z axis driven by step motor | ||
| Board positioning | Customized fixtures | ||
| PCB thickness | 0.4~4mm | ||
| Load/unload method | Manual | ||
| Error alarm | Yes | ||
| Program method | Self programing,camera controlled by keyboard and mouser | ||
Application:
PCB board cutting
The desktop router can quickly and accurately cut PCB boards and separate parts such as motherboards and circuit boards.
Complex shapes can be cut according to design drawings.
Slot and hole processing
Various slots, grooves and holes can be made on PCB boards to meet the needs of circuit layout.
These processes help install components and route wires.
Edge trimming
The router can trim and polish the edges of PCB boards to improve the appearance quality of the product.
Burrs and rough edges on PCB boards can be removed.
Small batch production
Desktop routers are suitable for small batch PCB processing, with strong flexibility and the ability to respond quickly to customer needs.
Compared with large CNC equipment, the investment cost is lower and it is suitable for small and medium-sized electronic manufacturing companies.
Prototype production
In the early stages of product development, desktop routers can be used to quickly make prototypes for testing and verification.
This helps shorten the development cycle and speed up the introduction of new products to the market.
Machine details
