| Brand Name: | HSTECH |
| Model Number: | HS-200A |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per week |
DC24V Chargable 100KG Load Capacity Rubber Strip Automated Guided Vehicles
Introduction
As an economical option, this AGV trolley uses batteries as its power source and is able to move accurately to a predetermined position by following the rubber tape guide. Its unique transfer station design allows users to configure it freely, which greatly enhances the convenience of material transfer, thus significantly reducing manpower input and achieving an efficient workflow.
Features
1. Load capacity: the standard load capacity is 100kg, meanwhile, customised service is provided to meet the different load requirements of customers.
2. Battery life: Adopting rechargeable battery technology, when the battery is fully charged, the trolley can continue to run for a whole day, ensuring efficient and continuous working condition.
3. Battery type selection: lead-acid batteries and lithium batteries are available for customers to choose according to their own needs. Both types of batteries support charging to ensure the continuous supply of energy.
4. Moving direction setting: the moving direction of the trolley is flexible and adjustable, and the factory is free to paste adhesive strips to guide the travelling path of the trolley.
5. Terminal marking: The terminal is marked by sticking black tape on the adhesive strip, which makes the operation more intuitive and easy.
Specification
| Product name | AGV transport car |
| Model | HS-200A |
| Machine dimension | 760*420*350mm |
| Guide Method | rubber strip guidance |
| Driving Method | Dual-wheel differential driving |
| Load Capacity | 100kg(or customized) |
| Driving power | DC24V |
| Moving speed | 0-50m/min |
| Turning radius | min 800mm(car body) |
| Navigation accuracy | ±10mm |
| Continuous working time | >24h |
| Gradeability | 3-5degree |
| Stop accuracy | ±10mm |
| Lifting height | 50mm |
| Battery charge method | Manual charging |
| Safety induction range | ≤3m,can be adjustable |
| Emergency brake distance | <20mm |
| Battery | Li Battery |
| Alarm |
light and sound alarm
|
