| Brand Name: | HSTECH |
| Model Number: | HS-200A |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per week |
Rubber Strip Guided AGV Transport Car with 100KG Load Capacity for Material Handling
Introduction
This AGV trolley is an economical vehicle, powered by batteries, the trolley moves according to the guidance of the rubber belt to reach the set location, and it is also free to set up a transfer station, which makes it very convenient to transfer materials and saves a lot of manpower.
Features
1, Loading capacity 100kg, or customized.
2, Chargable battery, when the battery is full, the car can operation the whole day.
3, Lead-acid battery or Li battery options, customers can make the choice, both batter can be charging.
4, The moving direction can set freely, factory can paste the rubber strip freely.
5, Paste the black strip onto the rubber strip, that means it's a terminal.
Specification
| Product name | AGV transport car |
| Model | HS-200A |
| Machine dimension | 760*420*350mm |
| Guide Method | rubber strip guidance |
| Driving Method | Dual-wheel differential driving |
| Load Capacity | 100kg(or customized) |
| Driving power | DC24V |
| Moving speed | 0-50m/min |
| Turning radius | min 800mm(car body) |
| Navigation accuracy | ±10mm |
| Continuous working time | >24h |
| Gradeability | 3-5degree |
| Stop accuracy | ±10mm |
| Lifting height | 50mm |
| Battery charge method | Manual charging |
| Safety induction range | ≤3m,can be adjustable |
| Emergency brake distance | <20mm |
| Battery | Li Battery |
| Alarm |
light and sound alarm
|
