| Brand Name: | HSTECH |
| Model Number: | HS-200A |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per week |
Rubber Strip Guided Automated Guided Vehicle with 3-5degree Gradeability
Introduction
This AGV car is a economic vehicle, which is powered by battery, the car is moving according to the rubber tape guidance to reach the setted place, also can set the transfer station freely, it's very convenient to transfer the materials, save much labor.
Features
1.Strong and stable mechanical design.
2.PLC control system , and the time of PCB sheet feeding is less than 5 seconds.
3.Control panel is LED true color touch screen.
4.The lifting power adopts single-phase gear reduction motor.
5.The lifting platform adopts aluminum plate machine plus parts, which is high in precision and not easy to change.
6.Upper and lower pneumatic clips can ensure that the bin position is more accurate and good.
7.The lifting platform is equipped with working sensor and limit brake, which double guarantees the material box.
8.Step distance can be divided into 4 types (10, 20, 30, 40 mm).
9.Automatic detection of fault code display function.
10.Device status indication: three-color lamp with buzzer
11.With anti-card board special anti-stupid structure to ensure that the PCB board is not damaged.
12.Compatible with SMEMA interface, can be connected online with other devices.
Specification
| Product name | AGV transport car |
| Model | HS-200A |
| Machine dimension | 760*420*350mm |
| Guide Method | rubber strip guidance |
| Driving Method | Dual-wheel differential driving |
| Load Capacity | 100kg(or customized) |
| Driving power | DC24V |
| Moving speed | 0-50m/min |
| Turning radius | min 800mm(car body) |
| Navigation accuracy | ±10mm |
| Continuous working time | >24h |
| Gradeability | 3-5degree |
| Stop accuracy | ±10mm |
| Lifting height | 50mm |
| Battery charge method | Manual charging |
| Safety induction range | ≤3m,can be adjustable |
| Emergency brake distance | <20mm |
| Battery | Li Battery |
| Alarm |
light and sound alarm
|
