Smooth And Precise Rotation PCB Inverter PCB Flipper With SMEMA Compatible

Brand Name:	HSTECH
Model Number:	HS-IT350/HS-IT500
MOQ:	1 PC
Price:	Negotiable
Payment Terms:	D/P, T/T, Western Union, MoneyGram
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

PCB Inverter Machine

Material:

Stainless Steel

Transport Height:

910±20mm

Transportaion Direction:

L~R,R~L

Air Pressure:

4-6bar

Pcb Thickness:

Min 0.6mm

Packing:

Wrap, Wooden Box

Warranty:

1 Year

Packaging Details:

Wooden Case

Supply Ability:

50 sets per month

Highlight:

Precise Rotation PCB Flipper

PCB Inverter PCB Flipper

SMEMA Compatible PCB Flipper

Product Description

Smooth And Precise Rotation PCB Inverter PCB Flipper With SMEMA Compatible

Introduction:

A PCB Inverter Machine is a specialized piece of equipment used in the electronics manufacturing industry, primarily for the production and assembly of printed circuit boards (PCBs). These machines are designed to perform a variety of functions related to PCB manufacturing, including the inversion (flipping) of PCBs during assembly processes.

Features

1, Enclosed design with built-in torque limiter ensure high level

of safety.

2, Top safe cover can be opened for each access to hardware

during Maintenance.

3, Use friendly control button,optional use touch screen.

4, Smooth and precise rotation.

5, By-pass model provided.

6, Minimize the transfer gap between conveyors.

7, PCB traffic flows can be customized.

8, Smooth and parallel width adjustment(lead screw).

9, SMEMA compatible.

1. Functionality

Inversion of PCBs: The primary function is to flip or invert PCBs to allow for assembly on both sides. This is essential in multi-layer PCB production where components need to be placed on both sides of the board.
Alignment and Positioning: Many machines come equipped with mechanisms to ensure that PCBs are aligned correctly during the inversion process, which is critical for accurate component placement.

2. Key Features

Automated Operation: Many PCB inverter machines are automated, reducing the need for manual handling and improving efficiency.
Adjustable Parameters: Operators can often adjust settings such as speed and height to accommodate different PCB sizes and designs.
User-Friendly Interface: Modern machines typically feature touchscreen controls for easy operation and monitoring.

3. Applications

Electronics Manufacturing: Widely used in the production of consumer electronics, automotive components, and communication devices.
Prototype Development: Useful for quickly assembling prototype PCBs that require components on both sides.
