| Brand Name: | HSTECH |
| Model Number: | HS-S5331R |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets per month |
Single Head/tip Desktop Soldering Robot with Stepper Motor,Timing Belt
Features:
Equipped with a display that allows for a comprehensive view of the entire working process.
Features two workstations and a rapidly switchable soldering system, eliminating the time consumed in assembling and disassembling fixtures.
An independently developed intelligent control system, boasting powerful functionalities and a user-friendly operation interface.
With an extensive process library, programming has become simpler and more efficient.
Optional universal auxiliary fixture parts, enabling fixtures to be quickly and easily assembled on-site.
High-quality and dependable mechanical structure, requiring no maintenance.
A high-power heating controller ensures the stability of continuous welding, with the robot control system managing full-time temperature monitoring and control.
A smoke purification filter system extends the lifespan of the soldering iron and enhances soldering quality.
The machine includes an automatic cleaning function, enhancing the stability of soldering processes and prolonging the lifespan of the soldering iron.
Specification:
| Model | HS-S5331R |
| Voltage | AC110V/220V,50/60Hz |
| X/Y1/Y2/Z working range | 500*300*300*100mm |
| R axis | 360 degree |
| X/Y1/Y2/Z moving speed | max 300mm/s |
| Driven system | Stepper motor,timing belt |
| Linear guide | Taiwan brand high precison guide |
| Repeat accuracy | ±0.02mm |
| Programing | Manual programmin with teach pendant |
| Control system | Control board |
| Program storage |
It can store one thousand sets of processing data and a single
processing file can occupy up to 3M storage space
(five thousand processing points)
|
| File storage space |
Handheld box 256M, offline card 32M, single processing file up to
3M storage space (100,000 processing points)
|
| Document support | CAD |
| Iron Tin cleaning | Air cleaning/pneumatic |
| External interface | USB+RS232 |
| Soldering method | Point/drag soldering |
| Weight | 60kg |
| Machine dimension | 680*585*800mm |
Application:
The automatic soldering machine is predominantly utilized in the electronics manufacturing industry, particularly for intricate processes and solder applications that are challenging to achieve through reflow soldering and wave soldering methods.
It is ideally suited for mixed circuit boards, heat-sensitive components, and delicate devices during the SMT back-end process. This machine is widely applied in various fields, including PCB board welding lines, charger plug welding, connector soldering, DC end tinning, LED light strip connections, and more.
Automatic soldering robots have replaced manual soldering, significantly enhancing work efficiency and improving the quality of solders. They are suitable for a range of production industries, including automotive electronics, digital and electronic products, LCDs, circuit boards, and others. These robots excel in quality welding for connectors, RJ/network transformers, cables, FPCB welding, COF welding, computer motherboards, CABLEs, speakers, and motors.
