Dual Platform 360 Degree Solder Tip Tabletop Soldering Machine With Stepper Motor

Dual Platform 360 degree Solder Tip Tabletop Soldering Machine with Stepper motor,timing belt

Introduction:

This advanced automatic soldering system boasts a dual-table setup, featuring a solitary soldering head equipped with two independently temperature-controlled soldering irons. Although it lacks a rotation capability, it is meticulously designed for both standard PCB board soldering tasks and production line applications. The system's dual soldering irons operate simultaneously, dramatically enhancing soldering efficiency. It runs on a combination of air pressure and electricity, and includes an intuitive teach pendant box for manual, point-by-point programming, which then seamlessly transitions to automated soldering upon completion of programming.

Key Features

Compact Tabletop Design:
Crafted for tabletop deployment, this soldering machine is an optimal solution for confined workshops, scientific laboratories, and streamlined production lines, maximizing space efficiency.

Highly Adjustable Temperature Control:
With a versatile range of temperature settings, users can fine-tune the soldering process to precisely match the requirements of their solder material and electronic components.

Dual Operating Modes:
This machine elegantly merges the ease of automatic soldering with the accuracy of manual control, granting users the adaptability to tackle a wide array of tasks with confidence.

Versatile Soldering Capabilities:
Equipped with either a high-performance soldering iron or a hot air gun, it supports multiple soldering techniques, enhancing overall productivity and flexibility.

Comprehensive Safety Measures:
Featuring built-in safety features such as automatic shut-off and thermal protection, it guarantees a secure and stress-free soldering experience, safeguarding both users and equipment.

Intuitive User Interface:
Whether through a straightforward control panel or an advanced touchscreen, it offers an intuitive user experience, making operation straightforward and trouble-free.

Benefits

Enhanced Production Efficiency:
This system drastically speeds up production through swift and consistent soldering of components, fostering a seamless workflow and elevated productivity levels.

High-Precision Soldering:
Its unmatched accuracy greatly reduces the risk of damaging sensitive electronic components, thereby safeguarding the integrity and dependability of the finished product.

Versatile Applications:
Highly adaptable, it caters to a wide range of applications, encompassing creative prototyping, flexible small-batch manufacturing, intricate repairs, and routine maintenance tasks.

Cost-Effective Investment:
As a compact, tabletop system, it offers a budget-friendly option for small enterprises and startups, delivering advanced soldering functionalities without the steep costs associated with larger, industrial-sized automated systems.

Applications

Electronics Manufacturing:
Widely utilized in the assembly of PCBs for consumer electronics, automotive parts, and industrial machinery.

Prototyping:
Perfect for R&D settings where swift prototyping and circuit testing are essential.

Repair Services:
Employed in electronics repair shops to mend or replace components in malfunctioning gadgets.

Hobbyist Projects:
Favored by electronics hobbyists for DIY endeavors and bespoke circuit designs.

Features:

1. Dual-Table Configuration with Dual-Iron Single Moving Head:
   This innovative soldering system features a dual-table arrangement, coupled with a single moving head equipped with two soldering irons, thereby optimizing workspace efficiency.

   Individually Controlled Temperature Settings for Each Iron:
   Each soldering iron features its own temperature controller, enabling precise temperature adjustments tailored to specific soldering needs.

   Eco-Friendly Nitrogen-Free Soldering:
   By adopting nitrogen-free soldering irons, this machine promotes environmental sustainability while ensuring operator safety.

   Flexible Multi-Directional Head Adjustment:
   The soldering head can be tilted using a radial fixture, allowing for multi-directional adjustments to protect delicate PCB boards and components from accidental damage.

   Precision Motion Control System:
   Powered by a high-precision stepper motor and timing belt drive, combined with advanced motion control algorithms, this machine ensures exceptional positioning accuracy and repeatability.

   Integrated Automatic Cleaning Feature:
   The machine's built-in automatic cleaning function enhances soldering stability and extends the lifespan of the soldering irons, reducing maintenance costs.

   Intuitive Handheld Teach Pendant:
   The user-friendly handheld teach pendant simplifies programming, making it quick and easy to learn, even for beginners.

Specification:
