Multi-Angle Soldering with Automatic Soldering Robot and Hiwin Linear Guide

Desktop Soldering Machine Manual Teaching Box with Hiwin Linear Guide Brand

Introduction:

This widely-used automatic desktop soldering machine employs a teaching box for manual programming and utilizes top-notch stepper motors and timing belts for its operation. It provides options for either single or double workstations, featuring a standard travel range of 300*300mm that can be tailored to suit specific customer product needs.

Application:

1. Semiconductor Products: This category includes LSI (Large Scale Integration), ICs (Integrated Circuits), Temperature Combination ICs, CSPs (Chip Scale Packages), BGAs (Ball Grid Arrays), and other related components.

2. Optical Products: High-quality, first-class cameras are included in this category.

3. General-Purpose Home Appliances: This encompasses DVD players, audio equipment, automotive navigation systems, personal computers, cameras, electronic clocks and watches, PDAs (Personal Digital Assistants), photocopying calculators, and liquid crystal TVs, as well as medical devices.

4. Precision Machinery/Electrical Products: VTRs (Video Tape Recorders) are among the products in this category.

5. General Consumer Goods: This category includes typewriters, toys, musical instruments, CDs, batteries, and other everyday items.

Features:

1. This machine offers 4-axis operation, incorporating X/Y/Z movements and R rotation, which allows for multi-angle soldering capabilities.

2. It features an automatic cleaning function that utilizes a soldering iron/tip without nitrogen, ensuring both safety and environmental protection.

3. High precision and accuracy in movement are achieved through the incorporation of Taiwan's Hiwin linear guides.

4. The control system employs a reliable control board and is also compatible with PLC for versatile programming options.

5. The Iron head serves as a reference point for aligning the product's key position. Simply pressing the enter key automatically registers this point in the system, facilitating subsequent data settings.

6. By combining high-precision stepper motors and timing belts with advanced motion control algorithms, the machine significantly improves motion positioning accuracy and repeatability.

7. The automatic cleaning function helps stabilize the soldering process and extends the lifespan of the soldering iron.

8. Programming the machine is intuitive with the handheld LCD teaching pendant, offering both high precision and user-friendly operation.
