Introduction:

This advanced automatic soldering machine features a dual-station soldering table, designed for efficiency and precision. It boasts a single soldering head equipped with two soldering irons, each independently controlled by two temperature regulators. Notably absent, however, is a rotation function. Ideal for standardized PCB board soldering or production lines, this model harnesses the power of both soldering irons simultaneously, significantly enhancing soldering speed and throughput.

Operating on a combination of air pressure and electric drive, the machine utilizes an intuitive teach pendant box for manual point-by-point programming. Once programmed, it seamlessly transitions into automatic soldering mode, streamlining the process and ensuring consistent, high-quality results.

Features:

Here's a revised version that incorporates all the points you've mentioned:

1. This automatic soldering machine boasts a dual soldering table, allowing for parallel processing. It features a single moving head, but uniquely equipped with two soldering irons, maximizing efficiency.

2. Each soldering iron is individually temperature-controlled, ensuring precise heat management tailored to specific soldering requirements.

3. The soldering irons operate without nitrogen, making them not only safe but also environmentally friendly, minimizing potential hazards and emissions.

4. For added versatility and protection, the soldering head can be tilted using a selectable radian fixture. This multi-directional adjustment capability safeguards PCBs and components from accidental damage during the soldering process.

5. The machine employs high-precision stepper motors and a timing belt drive system, coupled with advanced motion control algorithms. This combination significantly enhances motion positioning accuracy and repeatability, ensuring consistent soldering results.

6. Equipped with an automatic cleaning function, the machine maintains stable soldering performance over time. This feature also extends the lifespan of the soldering irons, reducing maintenance costs and downtime.

7. Programming the machine is straightforward and user-friendly, thanks to the handheld teaching pendant. This intuitive interface simplifies the learning curve, allowing operators to quickly master the programming process.

Compact design:
Fits in small workspaces, easy to move and operate.

Temperature control:
With adjustable temperature settings, suitable for different types of solder and components.

Automation function:
Some models offer automatic soldering function to improve soldering speed and consistency.

Multiple soldering techniques:
Supports multiple soldering methods, such as manual soldering, hot air soldering, etc.

User-friendly interface:
Usually equipped with a simple control panel or touch screen for easy operation and setting.

Application areas
Electronic manufacturing:
Widely used in small batch production or prototype development.

Repair and maintenance:
Suitable for repair and parts replacement of electronic products.

Education and training:
In electronic engineering courses, used for teaching and practice.

Advantages
High efficiency:
Increase soldering speed and reduce production time.

Soldering quality:
Provide stable temperature control to ensure soldering quality.

Flexibility:
Suitable for many types of electronic components to meet different needs.

Specification:

Application Scenarios:

Electronic Manufacturing
Widely used for component welding in small batch production and prototype development.

Laboratory R&D
Suitable for various welding experiments and tests in laboratory environments.

Repair and Service
Can be used to repair and replace damaged components in electronic devices
