Automatic Magazine Alignment 90W Brake Motor Drive PCB Unloader for SMT Line End

Automatic Magazine Alignment 90W Brake Motor Drive PCB Unloader for SMT Line End

Introduction:

It is a device for automatically removing printed circuit boards (PCBs).

Functions and applications:
1.Automatically remove PCB boards from the discharge ports of SMT placement machines, reflow ovens and other equipment.
2.Transfer PCB boards to subsequent processes, such as inspection and sorting, in an orderly and safe manner.
3.Improve production efficiency, reduce manual intervention, and reduce the risk of PCB damage.

Main structure and working principle:
Conveyor belt: Responsible for conveying PCB boards from the equipment discharge port to the Unloader.
Clamping mechanism: Using vacuum suction cups or mechanical clamping claws, it can flexibly clamp PCB boards of different sizes.
Lifting mechanism: Control the lifting and lowering of the clamping mechanism to remove the PCB board from the conveyor belt.
Transfer mechanism: Transfer the removed PCB board to a specified position, such as a placement rack or subsequent conveyor belt.
Control system: Automatically control the actions of each actuator according to the device sensor signal.

Performance parameters:

1. Clamping size range: From tens of millimeters to hundreds of millimeters.
2. Clamping frequency: Up to dozens of PCBs per minute.
3. Positioning accuracy: Usually within ±0.1 mm.
4. Operation stability: Continuous operation for tens of thousands of hours without failure.

Advantages and features:

• Improve production efficiency and consistency, reduce labor costs.
• Protect PCB boards from damage and improve yield rate.
• Can be seamlessly connected with other equipment in the SMT production line.
• Suitable for automatic unloading of PCB boards of various specifications.

Specification
