| Brand Name: | HSTECH |
| Model Number: | HS-C510F |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets per month |
High Accuracy PCB Handling Equipment with CCD Mark Point Location Barcode Reading
Specification
| Model | HS-C510F |
| Working method | Laser head moving |
| Leaser brand | SYNRAD CO2(America brand) |
| FIducial location | CCD+Mark positioning |
| Inline reading | Camera inline reading |
| PCB thickness | 0.5~5.0mm |
| PCB dimension | 50*50~510*460mm |
| Transpoting height | 900±20mm |
| Transportation direction | L-R/R-L |
| Width adjustment | Automatic |
| XY control system | PC+board card+servo motor |
| XY control accuracy | ±0.02mm |
| Wrong material recognition | Nagative board/Reverse/wrong recognition |
| Bad mark recognition |
Auto recognition bad mark, wont mark bad marks |
| Anti recode | Supported |
| Control system | Win7+self developed system |
| Power supply | Single phase AC 220V 16A 50/60Hz |
| Air pressure | ≥0.5 Mpa |
| Dimension | W1000*L1600*H1700 (mm) |
| System import | SHOP FLOW MES IMS SFIS,etc |
| Dimension | W1000*L1600*H1700 (mm) |
| Weight | 700 KG |
Features
1, CCD Mark point location
2, CCD inline barcode reading
3, CCD barcode quality analysis
4, X Y servo driver, accuracy±0.02mm
About Packaging
COMPANY PROFILE
Shenzhen Hansome Technology Co.,Ltd(HSTECH)is a professional professional SMT board handlingequipment(Loader,Unloader, Buffer, Conveyor,etc)manufacturer, We are a high-tech enterprise with independent intellectual propertyrights,the company is mainly engaged in the research and development, productionand sales of sMT/THT production line board handling equipment.We have professional technicians & sales,relies on high-tech and tries our best tosupply high efficient and reliable board handling to our customers. At the same time,our experienced engineering team always grasps smart factory's developing directionupdates the products and technical according to the market demand, pursuit to makemore automation and cost-effective product all the time, we also do the OEM basedon different needs of our customer.
