| Brand Name: | HSTECH |
| Model Number: | TM-M-90D |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
SMT production line anti-static belt type 90 degrees printed circuit board turnover processor
Introduction
This 90degree turning machine is used to change the flow direction of a PCB assembly line, it can turns to clockwise or counter-clockwise.
Specification
| Type | TM-M-90D | TM-L-90D | TM-LL-90D | TM-XL-90D |
| Size | M | L | LL | XL |
| PCB Size(mm) | 330*50*250 | 445*50*330 | 535*50*390 | 535*50*460 |
| Cycle time | 10 secs | |||
| PCB direction | left to right | |||
| Transport height(mm) | 900±20 | |||
| Power supply | AC110V,AC230V,1ph | |||
| Current | max 250A | |||
| Air pressure | 4-6bar | |||
| Air consumption | max 1.5Itr/min | |||
| Machine size(mm) | 500*560*1170 | 650*710*1170 | 800*890*1170 | 950*1080*1170 |
| Weight(kg) | 160 | 175 | 190 | 200 |
| Turning angel | used to redirect pcb flow to90 degree,180degree,or 270degree | |||
Features
1, PLC control system.
2, Enclosed design with built-in torque limiter ensures highest level of safety.
3, Rotate accurately by using motor.
4, Optical sensors installed for safety.
5, 90degree turning and pass through mode selective.
6, Standard SMEMA.
We have more than 10 years' professional SMT industry experience. With strict production,inspectiondebugging and packaging process, we insist on providing clients with good service pre-sales, in-salesand after-sales services. We have professional QC person to check the quality of the equipment andspare parts. After manufacturing, all equipment will be carefully tested and debugged before shipment.
At Shenzhen Hansome Technology, we strive for excellence in delivering cutting-edge technology and exceptional customer service. We look forward to the opportunity to serve your business needs. Should you have any questions or require further information, please do not hesitate to contact us!
