| Brand Name: | HSTECH |
| Model Number: | HS-330BF |
| MOQ: | 1set |
| Price: | Negotiable |
| Payment Terms: | D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
Features:
1. With FIFO and By-pass function, or cutomized to multiple function.
2. Soft touch LED control panel.
3. Using servo motor for accuracy positioning.
4. Leadscrew for width adjustment, smooth and stable.
5. The whole machine is small volume, won't take much factory space.
6. SMEMA communication interface, can be connected with other automation equipment.
7. Three color LED display for machine status.
Specification:
| Model: | HS-330BF | ||||
| Voltage: | AC220V,50/60Hz | ||||
| PCB Dimension: | L(50*50)-(450*330)mm | ||||
| Air supply: | 4-6 bar,max 15L/min | ||||
| Transport height: | 900±20(mm) | ||||
| Transport Direction: | L-R or R-L (optional) | ||||
| PCB thickness: | min 0.46mm | ||||
| Up/down pitches: | 1-4(10mm step) | ||||
| Store Capacity | 25pcs or customized | ||||
| Cycle time | Around 15 seconds | ||||
| Communication | SMEMA | ||||
| Machine Dimension: | 600*1150*1560mm | ||||
| Gross Weight: | 280kg | ||||
