| Brand Name: | HSTECH |
| Model Number: | HS-120ST |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 50 sets per month |
Industrial Ultrasonic Cleaner 38L Capacity for Oil Dirty Hardware Parts Cleaning
Features
High-Performance Transducer for Thorough Cleansing:
This transducer stands out in its cleaning prowess, delivering visible results even under meticulous macroscopic examination.
Radiant, Polished Finish After Cleansing:
Objects emerge with a dazzling gloss post-cleaning, exhibiting a refreshed and revitalized look.
Precise Digital LCD Panel for Accurate Customization:
The digital LCD panel allows for fine-tuning of startup times, enhancing user experience and ease of operation.
Elegant Design with Premium Stainless Steel:
Crafted from superior stainless steel, the lid and chamber exhibit a sophisticated elegance, enhancing the overall aesthetic appeal.
Advanced Water Resistance for Enhanced Safety:
Improved waterproof capabilities ensure greater safety and durability, making the product more reliable.
Stable Temperature System for Optimal Efficiency:
Equipped with a heating system, the consistent temperature mechanism guarantees reliable performance throughout usage.
Specification
| Model | HS-120ST |
| Ultrasonic frequency | 28/40 kHz |
| The tank material | Stainless steel SUS304 stamping slot |
| Tank capacity | 38L |
| Timer | 1~99 min adjustable |
| Heater | 0 ~80℃ adjustable |
| Power | AC 100 ~ 120 V, 60 Hz/AC 200 ~ 240 V, 50 Hz |
| Ultrasonic power | 40~600 W adjustable, 12 transducers |
| Heating power | 1500W |
| The tank size | 500 x 300 x 250 mm (L x W x H) |
| Shape dimension | 670 x 480 x 700 mm (L x W x H) |
| N.W | 30KG |
| G.W | 35KG |
| Certification | CE,RoHS |
Ultrasonic device
Ultrasonic Installation Configuration:
The system employs a bottom-mounted shock plate installation method to guarantee effective ultrasonic wave transmission.
Strategic Vibrator Layout & Adjustable Power Range:
At the tank's base, a meticulously arranged array of 72 vibrators offers a versatile ultrasonic power range that can be adjusted from 0 to 3600W, tailored to meet specific cleaning requirements.
Dual Modular Ultrasonic Generator with Adjustable Power:
The system is equipped with two ultrasonic generator modules, each capable of delivering a continuously adjustable power output ranging from 0 to 1800W. The ultrasonic frequency can be selected between 28KHz and 40KHz, accommodating a broad spectrum of cleaning applications.
Premium Industrial Transducer with Longevity:
The ultrasonic transducer boasts a robust industrial shock head sourced from South Korea, renowned for its superior cleaning capability and extended service life, ensuring enduring reliability.
Advanced Bonding for Enhanced Strength and Durability:
Utilizing state-of-the-art bonding technology from Korea and imported specialty adhesives, the transducer is bonded to the vibrating surface with exceptional strength. This eliminates the risk of degumming, ensures stable performance, and all transducers are reinforced with high-frequency wires for superior durability.
