| Brand Name: | HSTECH |
| Model Number: | HS-SL5331 |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100pcs per month |
Features
Compact Versatility: Effortlessly integrates into any production environment, maximizing floor space utilization and simplifying tool transitions for seamless process flow.
Advanced Quality Assurance: Automates detection of absent fasteners, guaranteeing impeccable product standards.
Dual Y-Axis Acceleration: Doubles the loading speed, resulting in substantial gains in productivity and output capacity.
Precision 4-Axis Flexibility: Boasting a spacious 500x300x300x100mm workspace, it tackles intricate, high-precision tasks with ease.
Operator-Friendly Design: Combines advanced automation with intuitive control interfaces for hassle-free operation.
Versatile Programming Capabilities: Enables customized setups through a user-friendly touchscreen and intuitive teach pendant programming, simplifying customization.
Unified Control Platform: Streamlines the management of multiple machines from a centralized control point, boosting overall operational efficiency.
Preventive Maintenance for Reliability: Regular screw inspections safeguard product integrity, preventing costly leaks and ensuring long-term reliability.
| Model | HS-SL5331 | |
| Production name | 4Axis Automatic Screw Locking Machine | |
| Moving range(X/Y1/Y2/Z) | 500*300*300*100mm | |
| X/Y1/Y2 axis moving speed | Closed loop motor :1-800mm/s | |
| Z axis moving speed | Closed loop motor: 1-300mm/s | |
| X/Y1/Y2 axis max load | Closed loop motor: 5KG | |
| Z axis max load | Closed loop motor: 3KG | |
| Power supply | AC110V/220V, 50/60Hz | |
| Repeat accuracy | ±0.02mm | |
| Document support | CAD CorelDraw | |
| Suitable screws | M1-M6 | |
| Machine dimension | 746*585*800mm | |
| Machine weight | 65kg | |
Main parts brand
1, Motor: Shinano 2, Guide: Hiwin 3, Photoelectric switch: Omron 4, Power supply: Meanwell
