High Precision 4 Axis Screw Fastening Machine for M1-M6 Screws Single Feeder

High Precision 4 Axis Screw Fastening Machine for M1-M6 Screws Single Feeder

Brand Name:	HSTECH
Model Number:	HS-SL5331
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

4Axis Automatic Screw Locking Machine

Feeding:

Suction Feeding

Axis:

4axis

Screws Compatible:

M1-M6, Or Customized

Moving Range:

500*300*300*100mm

Port:

Shenzhen

Oem:

Yes

Warranty:

1 Year

Packaging Details:

Wooden package, foam inside

Supply Ability:

100pcs per month

Product Description

High Precision 4 Axis Screw Fastening Machine for M1-M6 Screws Single Feeder

Introduction

The screw machine is a automtic equipment, with 4 axis moving system, double working station, single feeder, the whole machine composed of a feeding system and a lock-locking system, the feeding part responsible for screw-arrangement machine, is a relatively simple type of screw arranged in a row for the purpose of improving work efficiency. This screw lock machine is a automation equipment, widely used in the electronics industry. Compatible for screws from M1 to M6, other special screws, also can be customization.

Features

1.Customizable suction feeding system with single or double screw feeder.
2.High-quality electric screwdriver for precise Z-axis movement.
3.4-axis operation with a 500300300*100mm work area.
4..Dual workstations boost efficiency, allowing continuous product loading.
5.Accurate torque control and easy adjustment ensure quality output.
6.Quickly adaptable to M1-M6 screws by switching screw guides (custom options available).
7.Integrated leak detection automatically refills or alerts for missing screws.
8.Stores hundreds of processing files, each supporting 1000 screw entries, for instant recall.

Specification

Model	HS-SL5331
Production name	4Axis Automatic Screw Locking Machine
Moving range(X/Y1/Y2/Z)	500300300*100mm
X/Y1/Y2 axis moving speed	Closed loop motor :1-800mm/s
Z axis moving speed	Closed loop motor: 1-300mm/s
X/Y1/Y2 axis max load	Closed loop motor: 5KG
Z axis max load	Closed loop motor: 3KG
Power supply	AC110V/220V, 50/60Hz
Repeat accuracy	±0.02mm
Document support	CAD CorelDraw
Suitable screws	M1-M6
Machine dimension	746585800mm
Machine weight	65kg

Main parts brand

1, Motor: Shinano 2, Guide: Hiwin 3, Photoelectric switch: Omron 4, Power supply: Meanwell

About Product

High Precision 4 Axis Screw Fastening Machine for M1-M6 Screws Single Feeder 0

About Detail

High Precision 4 Axis Screw Fastening Machine for M1-M6 Screws Single Feeder 1
