Pcb V-Cut Machine Pcb Separator Linear Cutting Pneumatic Glass Fiber Board Fr4 Pcb Board

Safe and Pneumatic PCB Depaneling Machine PCB Depaneling Equipment Linear Guillotine Cutter

Introduction

This machine is pneumatically driven and electric control, built in 6 digits counter which is convenient for counting the cuts.

The linear knife type depaneling machines were designed to depanel prescored panelboards carefully, without bending or tension stress.Even sensitive SMD-components like ceramic capacitors will not be damaged by the depaneling process.

It suitable for all kinds of pcb board,LED aluminum board,COB board, cooper board,etc. It’s widely used, low cutting force stress, few cutting burrs,and the board side is smooth and flat, it’s a best choice for high quality board cutting.

Main functions are as follows:

Automatic depaneling
Adopting pneumatic driving mechanism, it can quickly and accurately depanel multi-layer PCB along the predetermined path.
It greatly shortens the time consumption of manual depaneling and improves production efficiency.
High-precision cutting
Equipped with professional tools and guide rail system, it can cut along the depaneling line designed for PCB.
Ensure the neat edge of PCB after depaneling, reduce burrs and damage.
Flexible adjustment
The cutting path and force parameters can be flexibly adjusted according to PCBs of different sizes and shapes.
It has strong adaptability and can be applied to depaneling of circuit boards of various specifications.
Safe and reliable
It is equipped with a safety shield to prevent operators from accidentally contacting moving parts.
The electronic control system can program the operating parameters to ensure stable and reliable operation.
Automation
It can be integrated with the production line to realize fully automatic depaneling and eliminate human intervention.
It is conducive to improving the automation level and consistency of the production line.


Features:

1.New type improved wireless sectional cutting technology is applied by this machine to handle operations for V-cut connecting plate and split board and effectively remove stress.

2.Easily adjust the blade gap, even highly sensitive SMD parts or ultrathin PC plate can be cut safely.

3. Activated parts driven is applied with no noise.

4.Thickness of the to-be-cut base plate: 0.5-2.0mm, max. length of 300mm PC plate.

5. Processing V-PCD plate, aluminum plate and CUT plate, etc

6. Controlled by electric pedal or pneumatic pedal, hoe knife plate splitting is completed by the motion of air cylinder.

Specification


Application:
Electronic product manufacturing:
Used to split multi-layer PCBs of mobile phones, tablet computers, electronic devices and other products.
It can achieve high-precision and high-efficiency board splitting operations.
Industrial automation:
Applied to the board splitting of industrial control equipment, instrumentation and other products.
Improve the degree of automation of production lines and reduce manual operations.
Medical electronics:
Applicable to the board splitting of medical equipment, diagnostic instruments and other circuit boards with high precision requirements.
Ensure the quality of board splitting and reduce product defective rate.
Aerospace field:
Used for PCB splitting with extremely high reliability requirements in the fields of avionics, aerospace equipment, etc.
Ensure that the circuit will not be damaged during the board splitting process.
Consumer electronics:
Widely used for PCB splitting of consumer electronics products such as mobile phones, laptops, digital cameras, etc.
Improve the efficiency of board splitting and reduce labor costs.
