KIC optimization software simplifies oven setup and reduces profiling to a single number
Introduction
The X5 has 7, 9, and 12 channel models, which can obtain a large amount of data, allowing you to accurately evaluate each heat profile and process in the factory. Measure slope, peak temperature, time above liquid, etc. The data is transmitted to your computer through a USB cable, and for RF models, it is wirelessly transmitted through an RF transmitter without the need for a cable connection.
KIC 'X5' Key Features
1. Robust hardware with a 2-year warranty
2. Wireless data transmission, equipped with RF models
3. Includes SPC (Statistical Process Control) software for document preparation and production optimization
4. Simplify oven settings: KIC's optimization software selects the best oven settings for each new product in seconds
5. User selectable setting standards
6. Reduce the configuration file to a single number: PWI (Process Window Index) allows operators, technicians, and engineers to clearly see how close the configuration file is to the specifications.
7. Instant file analysis: Objective and independent file analysis provides you with reliable information.
Specifications
| Model | KIC X5 |
| Dimension | 7-channel: 206 x 60 x 17 mm,with shield: 302 x 75 x 23 mm 9-channel: 206 x 75 x 17 mm,with shield: 312 x 90 x 23 mm 12-channel 206 x 98 x 17 mm,with shield: 323 x 113 x 23 mm |
| Accuracy | ± 0.5˚C |
| Resolution | 0.1˚C |
| Interal operating temp | 0˚C~85˚C |
| Sample rate | 0.1 to 10 readings/sec |
| Data points | 224,640 |
| Data transfer | Standard model USB 2.0 (Std-A/Mini-B) after datalogging run RF model Wireless over RF (radio frequency 433.92 MHz), sent real-time during datalogging run, or via USB 2.0 (Std-A/Mini-B) after datalogging run |
| Power | 3 AAA batteries, USB cable when connected to a computer |
| Thermocouple Capacity | Type K, standard (7, 9, or 12, depending on model) |
| Thermocouple Temperature Range | -150˚C to 1050˚C |
| Thermal shield | Cool Touch Stainless Steel 7 or 9 channel |
| Computer Configuration Minimum System Requirements |
Dual Core / 1 GHz processor PC w/2 GB RAM 2 GB available storage Video 1024 x 768 resolution, 16-bit 1 available USB port for data download 1 available USB port for software key |
