Original FUJI Nozzle H01/H02 5.0 7.0GH08M RH01 RH02 SMT Nozzle For Pick And Place Machine
Introduction
The nozzle is a very important component in SMT equipment such as automatic placement machines. Its main function is to accurately absorb and move electronic components to complete the automated surface placement process
Working principle
Vacuum system
The placement machine is equipped with a vacuum pump inside, which can generate a strong negative pressure.
The nozzle is connected to the vacuum pump through a pipeline to form a vacuum negative pressure system.
Nozzle structure
The nozzle consists of a nozzle head, a gasket, a nozzle cover and other components.
The central hole of the nozzle head is connected to the vacuum system to generate negative pressure.
Suction process
When the nozzle head is close to the component, the negative pressure will absorb the component.
The gasket and the nozzle cover can seal the nozzle head to prevent gas leakage.
Placement process
After the component is absorbed, the placement machine will move it accurately to the specified position.
During placement, the negative pressure will keep the component firmly absorbed.
After the placement is completed, the negative pressure will be released and the component will be easily released.
Main features
1.High-precision suction
The FUJI Nozzle uses advanced vacuum adsorption technology to accurately absorb SMD components of various sizes and shapes.
High suction force and high reliability ensure that components will not fall off during the mounting process.
2.Strong durability
The nozzle body is made of high-quality metal materials with excellent high temperature and wear resistance.
Long service life greatly reduces maintenance and replacement costs.
3.Strong flexibility
The FUJI Nozzle series offers a variety of specifications and sizes, which can be adapted to different models of automated mounting equipment.
Nozzles can be quickly replaced to meet various production needs.
4.Improve production efficiency
High-speed and accurate suction and mounting can greatly improve the efficiency of the entire SMT production line.
Reduce manual operations and reduce labor costs.
Nozzle material:
| Tungsten steel nozzle | Tungsten steel nozzle is strong and durable, but it is easy to turn white. If it turns white, use an oil-based pen to paint it, and you can continue to use it. |
| Ceramic nozzles | Ceramic nozzles never turn white, but are brittle and easy to break. Careful use can avoid or reduce breakage. |
| Diamond steel nozzle | It is strong, easy to use, and will never turn white, but it is very expensive and not cost-effective. |
| Glue nozzle | When the surface of the material is uneven or the material is sticky, it is suitable to use the glue nozzle. However, the life of the glue nozzle is not long. It is recommended to buy more glue nozzles for spare when ordering the glue nozzle. When the nozzle is worn, you can just replace it with the rubber nozzle yourself |
FUJI NXT Series NOZZLE:
NXT H08(H12) 2.5G nozzle,
AA73500 NXT H08(H12) 0.7 nozzle,
AA08500 NXT H01 3.7G nozzle,
AA08400 NXT H01 2.5G nozzle,
AA08300 NXT H01 20.0 nozzle,
AA08200 NXT H01 15.0 nozzle,
AA08100 NXT H01 10.0 nozzle,
AA08000 NXT H01 7.0 nozzle,
AA07900 NXT H01 5.0 nozzle,
AA07600 NXT H01 20.0G nozzle,
AA07400 NXT H01 10.0G nozzle,
AA07300 NXT H01 7.0G nozzle,
AA07200 NXT H01 5.0G nozzle,
AA07100 NXT H01 3.7 nozzle,
AA07000 NXT H01 2.5 nozzle,
AA06900 NXT H01 1.8 nozzle,
AA06400 NXT H08(H12) 1.3M nozzle,
AA06400 NXT H08(H12) 1.3G nozzle,
AA06300 NXT H08(H12) 5.0G nozzle,
AA05800 NXT H08(H12) 1.0 nozzle,
AA05800 NXT H01 1.3 nozzle,
AA05700 NXT H08(H12) 0.7 nozzle (0.7X0.5),
AA05600 NXT H08(H12) 0.4 nozzle (0.45X0.3),
AA20E00 NXT H08(H12) 5.0 nozzle,
AA20D00 NXT H08(H12) 3.7 nozzle,
AA20C00 NXT H08(H12) 2.5 nozzle,
AA20B00 NXT H08(H12) 1.8 nozzle,
AA20A00 NXT H08(H12) 1.3 nozzle,
AA19G00 NXT H08(H12) 1.8G nozzle,
AA18C00 NXT H08(H12) 3.7G nozzle,
AA11R00 NXT H01 1.8G nozzle,
AA08C00 or AA07L00 or AA07W00 or AA07D00 NXT H04 10.0 nozzle,
All item of nozzle for FUJI Pick and Place Machine
We sell SMT Nozzles of all brand ,such as YAMAHA, Panasonic, FUJI,JUKI,SAMSUNG ,etc.
