| Brand Name: | HSTECH |
| Model Number: | HS-600 |
| MOQ: | 1 set |
| Price: | 9000~12000usd/set |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 30 sets per month |
Data sheet of Pneumatic stencil cleaner HS-600.pdf...
SMT Cleaning Equipment Automated Stencil Cleaner w/ 3-Level Filter System
Features
1. The machine adopts high-quality SUS 304 stainless steel body, which is durable, stable, and has a beautiful appearance.
2. Driven by an air compressor, no electricity required, very safe, and harmless to the human body.
3. It has cleaning and drying functions, one click operation, and automatically dries the template after cleaning.
4. Two sets of spray bars, 360 degree rotating cleaning, high-quality nozzles, no cleaning dead corners, sufficient spray pressure.
5. Equipped with cleaning solvent inlet and outlet pipelines.
6. Three stage filtration system, 10um, 5um, 1um, cleaning solvent recovery, high cost-effectiveness, energy-saving.
After the template is placed in a safe clean room, it will be locked.
8. Modular design, automatic solvent siphon and discharge, fully automated operation, very efficient.
9. Easy to maintain, with the lid open, the operator can easily replace the filter.
Specification
| Model | HS-600 |
| Power supply | Compressor air |
| Application | stencil,metal mesh, steel mesh,cooper screen,gule screen |
| Stencil size | standard 29inch and below,740*740*40mm |
| Cleaning solvent | Alcohol |
| Cleaning liquid capacity | Max 45L,Min20L |
| Best cleaning fluid using volume | 40L |
| Liquid consumption | 120ml/pc |
| Cleaning method |
Rotary double side pressure injection and high pressure air |
| Cleaning time | 2~4 Min Stencil and Copper Screen |
| Drying time | 2~5 Min |
| External air supply | 0.4Mpa~0.6Mpa |
| Consumer air quantity | 400~600L/Min |
| Air outlet size | φ125*25mm |
| Solder dross filter mode | 3 level filter(10um,5um,1um) |
| Weight | 305kg |
| Machine dimension | 980MM(L)*700MM(W)*1730MM(H) |
Cleaning performance
