| Brand Name: | HSTECH |
| Model Number: | HS-500LC |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union, MoneyGram, D/P |
| Supply Ability: | 200 sets per month |
AC380V 8/10inch Blade 3600rpm Automatic PCB Lead Cutting Machine for Max 250mm PCB
Introduction
This machine is used for cutting the extra feet/lead of PCBA after wave soldering, the machine mainly including two parts, the PCB fixing, and the blade fixing. The PCB is transported by the chain, fixed by the clamper on both side, and the thimble at the buttom of the PCB. After the blade is fixed and the height setted, the PCB will be transported for the automatic lead cutting. The blade rotate fast and stability,at the same time it's very low noise and high efficiency. Warp prevention device is equipped to ensure no damage on the PCBA boards.
Feature
1.The automatic PC board cutting machine adopts eagle claw shrapnel clamp, which clamps the PC board and pushes automatically, with high stability.
2.The rail feeding speed can be finely adjusted according to the pins to enhance the life of the cutter.
3.The spindle speed is fast, the accuracy is high, and the production efficiency is fast.
4.With thimble ball and bakelite pressing plate, it can reduce the cutting error of PC board deformed by solder.
5.Automatic foot cutting machine is equipped with photoelectric control switch, high safety.
Specification
| Model | HS-500LC |
| Power | AC220, 50/60Hz/380V,50/60Hz |
| Max. PCB size | 400mm(L) x 250mm(W) |
| Main axis speed | 4500/Min |
| Main axis motor | 3/4 Hp |
| Guide rail speed | 0-3 M can be adjustable |
| Min. lead height | 1.0-1.5mm Min |
| Machine Demension | 750*600*860mm(W*D*H) |
| Net Weight | 115KG |
